Recycling Plant For Plastic To Oil Mini 1 Ton Capacity Waste Plastic To Fuel
Suitable raw material for the Plastic Pyrolysis Plant
There are many types of waste plastic are suitable for plastic pyrolysis machine , including woven bags, acrylic, packaging bags, disposable cups, freezer food bags etc.All plastics can be roughly divided into PP,PE,PS,ABS.
Application of the plastic pyrolysis oil
Plastic pyrolysis oil is a kind of heating fuel that can be sold directly to the boiler factories , steel factories , brick factories ,steel factories ,Cement Factories ,Power Plant etc.
We can provide the SGS plastic oil analysis report for customers reference.
Carbon black
It can be pressed into pellets for use in industrial heating. Pellets are a good alternative to coal as their calorific value is equivalent to that of coal. It can be ground and refined into different standards.
Oil ratio of different kinds of raw material
| Raw materials | Oil ratio |
| PP (Microwave oven food box/yogurt bottles, ect.) | 50%-75% |
| PS(fast food boxes/instant noodle boxes) | 50%-75% |
| PE(plastic film/plastic wrap) | 50%-75% |
| Plastic cable | 80% |
| ABS(engineering plastic) | 40% |
| Leftovers of paper | Wet 15-20%,Dry 60% |
| House garbage | 35%-50% |
| Plastic bags | 50% |
| Submarine cable | 75% |
| Rubber cable | 35% |
| Sole | 30% |
| Small tires | 45%-50% |
| Big tires | 35%-40% |
Parameter of rubber pyrolysis machine
| Item | Content |
| Raw materials | Waste tyre/rubber |
| Output | 45% fuel oil, 30% carbon black, 10% steel wire, 10%-15% syngas |
| Model | Reactor size | Capacity |
| HY1500*3000 | 1 T/batch |
| HY2000*4000 | 3T/batch |
| HY2200*6000 | 5 T/batch |
| HY2600*6000 | 7 T/batch |
| HY2600*6600 | 8 T/batch |
| HY2800*6000 | 9 T/batch |
| HY2800*6600 | 10 T/batch |
| HY2800*8100 | 15 T/batch |
| Reactor material and thickness | Q345R/Q245R/310S (Boiler plate/stainless steel) 14mm/16mm/18mm |
| The whole plant weight | 15-45 tons |
| Land area | 300-400m2(L30-40m*W10m) |
| Number of workers | 3-4 |
| Processing time and power | 10-24 hours. Averagely 15KW/h |
| Certification | CE, ISO, BV, SUV, SGS Oil Report, Emission Report, 11 patents |
Standing features of Huayin Tyre Pyrolysis plant for sale
A. Safety. We treat safety as the first important thing in production.
1. Two devices to avoid backfire in production: oil-water separator and anti-back fire device.
2. Vacuum device makes the reactor work under ordinary pressure or negative pressure.
3. Temperature monitoring and Pressure gauge to monitor the pressure. If the pressure goes above a certain level, the bell will alarm and the safety valve will release the pressure automatically.
B. Environmental protection
1. The flue gas (caused by burning fuel to heat the reactor) will be purified and cooled by a powerful ceramic packing dust removal device, then can be released into the air through the chimney.
2. Carbon black will be discharged out in sealed condition to avoid pollution.
C. Energy saving
1. The flame path is designed as a spiral so that the quantity of heat can be fully used.
2. The syngas is recycled to heating furnace for burning, thus saving your heating fuel.
3. The insulation cover is formed by 3 layers: steel plate, rock wool, and refractory cement. Excellent thermal insulation effect helps save fuel.
Our services
1. Help the client do the Feasibility Analysis Report according to the customer’s local market.
2. Design the layout drawings according to the site of customers.
3. For each set of pyrolysis plants, one engineer will be sent to guide the installation, test the machine and train the workers.
4. One-year warranty for the complete plant.
